Brand:Baopin
|
BP-8025-A |
|
DIN ABRASION RESISTANCE TESTER |
|
■Instruction This tester is designed to use together with a special balance for testing the abrasive consumption for the rubber products such as tire ,belt of tank,…etc. |
|
■Relational Products ■BP-8025-D ■BP-8025-N ■BP-8060-GB |
|
Specimen |
External dia 2 1/2″，interior dia 1/2″，thick1/2″，perimeter220mm, hardness 60～70° |
|
Abrasion Wheel |
External dia 150mm(W)25mm，granularity 36# |
|
Specimen Slanted Range |
0～45°（Test angle 15°） |
|
Specimen Rotating Speed |
（BS）250±5r/min (GB)76±2r/min |
|
Load |
2，6lb |
|
Balance hammer |
2.5kg |
|
Counter |
LCD，0～999，999 |
|
Dimension（W×D×H） |
570×520×450mm |
|
Weight |
57kg |
|
Power |
1∮，AC220V，3A |
